Cycloid Reducer Model Comparison Table
In the slow development history of the reducer, the cycloid reducer is a dazzling star in the entire reducer family. The earliest originated in Germany. Later, he developed in Japan, and his representative company was Sumitomo. It began to develop in China in the 1960s and 1970s, and has gradually grown and matured today. The standard model of cycloid reducer is also blooming. Now we have Shanghai standard cycloid reducer, Tianjin standard cycloid reducer, Ministry of Machinery standard, Ministry of Chemical Industry standard, Jiangmen standard, Ministry of Textile standard, Taiwan Shichuan, Japan Sumitomo and other models.
| Single-stage Machine Model Comparison Table of Each Series | ||||||||||
| Series Standards | Model | |||||||||
| X Tianjing | X2 | X3 | X4 | X5 | X6 | X7 | X8 | X9 | X10 | X11 |
| B Chemical Department | B0 | B1 | B2 | B3 | B4 | B5 | B6 | B7 | B8 | |
| B Machinery Department | B12 | B15 | B18 | B22 | B27 | B33 | B39 | B45 | B55 | |
| JXJ Jiangmen | JXJ0 | JXJ1 | JXJ2 | JXJ3 | JXJ4 | JXJ5 | JXJ6 | JXJ7 | JXJ8 | |
| BJ Textile | BJ2 | BJ3 | BJ4 | BJ5 | BJ6 | BJ7 | ||||
| B Shanghai | B10 | B11A/B11 | B12/B12B | B13/B13B | B14 | B14A | B15 | B16/B16B | B17 | B18 |
| Comparison Table of Various Series of Two-Stage Machine Models | ||||||||||
| Series Standards | Model | |||||||||
| X Tianjing | X32 | X42 | X53 | X63 | X74 | X84 | X85 | X95 | X106 | X117 |
| B Chemical Department | B10 | B20 | B31 | B41 | B52 | B53 | B63 | BB74 | B85 | |
| B Machinery Department | B1512 | B1812 | B2215 | B2715 | B3318 | B3322 | B3922 | B4527 | B5527 | |
| JXJ Jiangmen | JXJE10 | JXJE20 | JXJE41 | JXJE42 | JXJE52 | JXJE53 | JXJE63 | JXJE74 | JXJE85 | |
| BJ Textile | BJ42 | BJ53 | BJ63 | BJ74 | BJ84 | |||||
| B Shanghai | B110A | B120A | B131A | B142A | B142A | B152 | B153 | B163 | B173 | B184A |
Japan Sumitomo 6000 series cycloid pinwheel reducer standard products and model codes are listed: CHHM, CNHM, CHFM, CNFM, CHVM, CNVM, CVHM, CVFM,
CVVM, CWHM, CWFM, CWVM, CHHJM, CHFJM, CVVJM
List of special product and model codes: CHHXM, CHFXM, CVVXM, CHHPM, CVVPM, CPM, CHHBM,
CHFBM, CVVBM, CHHCM, C11WM, C 10CM, C14VM, C15VM, C17VM, C18VM, CPC
Taiwan Shichuan cycloid reducer models are: (THM607, THM608, THM609, THM610, THM611) (THM612, THHM613, THHM614, THHM615, THHM616) (THHM617, THHM618, THHM619, THHHM620, THHM621) (THHM622, THHM623) , THHM624, THHM625, THHM626) (THM607/07, THM608/07, THM609/08, THM610/08, THM611/08, THM611/09) (THHM613/08, THHM613/09, THHM613/10, THHM614/08, THHM614 /09, THHM614/10)
